Beskrivelse
03 EASY-FORM
THE ULTIMATE BENDING MACHINE
The Easy-Form precision press brake delivers top-of-the-line performance – high accuracy and productivity. This ultimate bending machine, based on the PPEB Series design, is enhanced with LVD’s patented Easy-Form® in-process angle correction and monitoring system. Easy-Form monitors the angle of the bend in real time and provides instant feedback to the TOUCH-B control so that each part is formed to the correct angle from the very first bend.
KEY FEATURES
- Patented Easy-Form® in process angle monitoring and correction system
- TOUCH-B touch screen graphical user interface control is intuitive and simple to use
- Bending parameters automatically controlled by LVD's unique 'intelligent' learning database
- 2D & 3D color graphics simulate part creation and display material handling sequencing
- CNC crowning V-axis standard for models over 2 meters
- Press brakes up to 400 ton/4 meter are designed and built using a welded one-piece frame for machine precision
- Enhanced Energy Reduction System (ERS)
- Turbo hydraulics (standard on 220-ton model and higher)
PERFORMANCE-ENHANCING OPTIONS
- CADMAN-B programming software
- Configurable options at point of order: open height, stroke, throat and gap, and more
- Six-axis modular backgauge
- Vertical W-style or LVD style (European style with adapter)
- Turbo hydraulics
- CNC sheet followers
MODELS
- Easy-Form-series – 8 axes: 80 tons by 1,5 meters up to 640 tons by 8 meters
Specifications
- Capacities from 80 tons to 640 tons
- Bending length from 1,5 meters up to 8 meters
- Bend accuracy to +/- 0.3 degrees
